Rigid Tapping, Movable Pendant Control, 30 Position Side Mount Tool Changer, Full Enclosure

Travel: X-Axis 40.2"
Y-Axis 20"
Z-Axis 19.7"
Table Size 45.3" x 19.3"
Spindle Speed 40 - 6000 RPM
Spindle Taper #40
Spindle Motor 25 HP
Tools 30
Table Load Capacity 1980 lbs.
Rapid Traverse Rates (X & Y / Z) 1200 / 787 IPM
Tool Change Time (T - T) 5.5 Seconds
Max Tool Diameter 2.95"
Max Tool Length 9.84"
Max Tool Weight 13.2 lbs.
Machine Dimensions (L x W x H) 102.2" x 85" x 103"
Machine Weight 8378 lbs.

FEATURES:
HEIDENHAIN CNC CONTROL
14" Color CRT
30 Position Side Mount Tool Changer
Rigid Tapping
Movable Pendant Control
Full Enclosure

102 x 85 x 103

8378
