Alpha Numeric Keyboard, Touch Screen Graphics, Rigid Tapping, Remote Manual Pulse Generator, Full Enclosure

Travel: X-Axis 30"
Y-Axis 20"
Z-Axis 20"
Table Size 37.4" x 20.47"
Spindle Speed 60 - 6000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 5" - 25.1"
Spindle Motor 7.5 HP
Tools 21
Table Load Capacity 1000 lbs.
Rapid Traverse Rates (X & Y / Z) 945 / 787 IPM
Tool Change Time (T - T) 7.5 Seconds
Max Tool Diameter 3.14" / 6.3"
Max Tool Length 15"
Max Tool Weight 14.96 lbs.
Machine Dimensions (L x W x H) 110" x 82.7" x 106.3"
Machine Weight 7275 lbs.

FEATURES:
ACRAMATIC 2100 CNC CONTROL
12" Color LCD
Touch Screen Graphics
Alpha Numeric Keyboard
Rigid Tapping
Remote Manual Pulse Generator
Full Enclosure

110 x 83 x 106

7275
