Auto Two Pallet Changer (Spin Type), 30 Position Side Mount Tool Changer, Coolant Thru Spindle (175 psi), Rigid Tapping, Remote Manual Pulse Generator, Spindle Chiller Unit, Yellow Operation Condition Light
Specifications:
Travel: X-Axis 22.0"
Y-Axis 15.7"
Z-Axis 22.4"
Table Size 25.6" x 17.7" (2)
Spindle Speed 80 - 10,000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 5.9" - 28.3"
Spindle Motor 15 / 10 HP
Tools 30
Table Load Capacity 660 lbs.
Rapid Traverse Rates (X & Y / Z) 1181 / 945 IPM
Max Tool Diameter 3.5"
Max Tool Length 11.8"
Max Tool Weight 17.6 lbs.
Machine Dimensions (L x W) 105" x 87"
Machine Weight 13,230 lbs.
FEATURES:
MITSUBISHI MELDAS 520M CNC CONTROL
9" Monochrome CRT
Auto Two Pallet Changer (Spin Type)
30 Position Side Mount Tool Changer
Coolant Thru Spindle (175 psi)
Rigid Tapping
Remote Manual Pulse Generator
Spindle Chiller Unit
