Table:
working surface : 1300 x 660 mm
max. payload : 1000 kg
T-slots ( size x number ) : 18 x 5 mm

Travel:
x- axis : 1020 mm
y - axis : 550 mm
z - axis : 560 mm

Distance Table top - spindle head: 150 - 710 mm
Distance surface - spindle centre : 600 mm

spindle :
speed : 15.000 U / min direct drive
spindle cone : NT 40
clamping system : pneumatic

feed:
cutting feed: 10. 000 mm / min
rapid traverse : X/Y/Z : 30/30/20 m / min
smallest input unit : 0,001 mm

tool changer :
tool holder : BBT 40
max. number of the tools : 32
Ø length of the tools : 77 x 300 mm
max. tool diameter, if adjacent places are free : 127 mm
max. tool weight : 7 kg
tool selection process : bidirectional

motors:
spindle motor: 18,5 kW
drive motor : X/Y/Z : 3,0/3,0/3,0 kW

mass of the machine :
footprint : 3260 x 3060 mm
machine height : 2790 mm
machine weight : 6000 kg

with Fanuc 21iMB control
complete covers
stand increase : 160 mm
spiral chip conveyor
Parkson PAR 250R hydraulic rotary -/ swivel table with interface
for 4. and 5. axis
linearguiding in 3 axis
180 rates reading ahead
air and coolant pistol

-
