Machine parameters:
Travels in X, Y, Z: 1000x1000x1000 mm
Clamping surface: 800x1000 mm
description:
The machine is in good technical condition, after previous agreement to testing. Power 44 kW Number of spindle speeds from 20 to 10,000 rev / min feed speed feed drive axes x, y, z, from 20 to 10,000 mm / min Rapid traverse 60 m / min measurement system tracks the x, y, z resolution 0.001 mm tolerance position 0, 01 mm Working range X-axis Y-axis 1000 mm 1000 mm 1000 mm Z axis working spindle SK 50 tool changer Places vzásobníku 60 pieces Max. tool weight 30 kg Max tool length 500 mm Workbench Clamping plate 800 x 1000 mm with a variety of table loading 1500 kg Total machine input kVA 82 Compressed air 20 m3 / h Machine weight without magazine 17500 kg 1900 kg weight stack control system Sinumeric 840 D
