x-travel 1000 mm
y-travel 800 mm
z-travel 500 mm
table surface area 1250 x 800 mm
spindle turning speed - stepless 1 - 15000 U/min
feed - longitudinal/cross 1 - 10000 mm/min
rapid traverse X- and Y-axis 30 m/min
rapid traverse: vertical 20000 mm/min
no. of tools in the magazine 30 Stück
spindle drive motor 15 kW
spindle taper ISO 40
spindle diameter in front bearing 70 mm
tool changing time 5 sec
max. tool-dia with free toolbox 80/140 mm
max. tool length 200 mm
total power requirement 40 kVA
weight of the machine ca. 9 t
dimensions of the machine ca. 3,7 x 3,2 x 3,1 m
