Auto Two Pallet Changer, Rigid Tapping, 20 Position Side Mount Tool Changer, Yellow Operation End Light, Full Enclosure
Specifications:
Travel: X-Axis 22"
Y-Axis 17.7"
Z-Axis 17.7"
Table Size 35.4" x 16.1" (2)
Spindle Speed 8000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 8" - 24"
Spindle Motor 10 HP
Tools 20
Table Load Capacity 770 lbs.
Rapid Traverse Rates (X & Y / Z) 1417 / 1181 IPM
Max Tool Diameter 3.7"
Max Tool Length 9.8"
Max Tool Weight 22 lbs.
Machine Dimensions (L x W x H) 82.6" x 89.7" x 96.9"
Machine Weight 10,560 lbs.
FEATURES:
SEICOS A10M CNC CONTROL
10.4" Monochrome CRT
Auto Two Pallet Changer
Rigid Tapping
20 Position Side Mount Tool Changer
Yellow Operation End Light
Full Enclosure
