WINMAX Software, Dual Color Screens, 12000 RPM Spindle Speed, Graphic Display, 24" Dia. Fourth Axis Rotary Table, +/- 90 Degree Head Swivel, 40 Position Side Mount Tool Changer, Two Color Tower Light, Chip Conveyor (Left Front Exit)
Specifications:
Travel: X-Axis 42"
Y-Axis 24"
Z-Axis 24"
B-Axis (Head Swivel) +/- 90 Degrees
C-Axis (Table Rotate) .001 Degrees
Table Size 50" x 24"
Spindle Speed 12,000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 6" - 30"
Spindle Nose to Rotary Table 0" - 17.6"
Spindle Motor 48 HP
Spindle Torque 87 ft. lbs.
Tools 40
Table Load Capacity 3000 lbs.
Rotary Table Load 1100 lbs.
Rapid Traverse Rates (X & Y / Z) 1378 / 1181 IPM
Cutting Feedrate 600 IPM
Tool Change Time (T - T / C - C) 4 / 7 Seconds
Max Tool Diameter 3.2"
Max Tool Length 11.8"
Max Tool Weight 15 lbs.
Machine Dimensions (L x W x H) 110.3" x 85.8" x 109"
Machine Weight 16,640 lbs.
FEATURES:
ULTIMAX CNC CONTROL
WINMAX Software
Dual Color Screens
12,000 RPM Spindle Speed
Graphic Display
24" Dia. Fourth Axis Rotary Table
+ / - 90 Degree Head Swivel
40 Position Side Mount Tool Changer
Two Color Tower Light
Chip Conveyor (Left Front Exit)
