table size : 410 x 900 mm
t-slot ( wide x number): 18x3
loading weight : 300 kg
travel longitudinal ( x- axis) : 585 mm
travel transversely (y - axis) : 430 mm
travel vertical ( z - axis) : 460 mm
distance table top - spindle head : 125 - 585 mm
distance stand - table center line : 205 - 655 mm
spindle cone : NST Nr. 40
speed : 20 - 7000 U / min
adjustable speed : 2 - steps
feed rapid traverse (x,y - axis): 24 m / min
rapid traverse : ( z - axis) : 20 m / min
cutting feed : 0 - 5000 mm / min
tool memory : 20
tool selection : directly control
tool holder : MAS BT40/ CAT 40
max. tool weigth : 8 kg
tool change time : 1,7 sec.
spindle motor : AC 7,5 / 5,5 KW
machine height : 2.948
footprint : 2.685 x 2.250 mm
machine weight : 4.500 kg

-
