Rigid Tapping, 20 Position Side Mount Tool Changer, Yellow Operating Condition Light, Turbo Chip Conveyor (Front Left Exit), Two Gear Range Headstock, Full Enclosure, Heavy Duty Box Way Construction
Specifications:
Travel: X-Axis 20.1"
Y-Axis 14.0"
Z-Axis 18.1"
Table Size 30.9" x 14"
Spindle Speed 20 - 10,000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 6.3" - 24.4"
Spindle Motor 15 HP AC
Spindle Torque 134 ft. lbs.
Tools 20
Tool Change Time (T - T / C - C) 1.2 / 3.2 Seconds
Gear Ranges 2
Rapid Traverse Rates (X & Y / Z) 1180 / 945 IPM
Max Tool Diameter 3.1" / 4.9"
Max Tool Length 11.8"
Max Tool Weight 17.6" lbs.
Machine Dimensions (L x W x H) 83.6" x 91" x 104.3"
Machine Weight 8820 lbs.
FEATURES:
YASNAC i80 CNC CONTROL
9" Monochrome CRT
Rigid Tapping
20 Position Side Mount Tool Changer
Turbo Chip Conveyor (Front Left Exit)
Full Enclosure
Yellow Operating Condition Light
Heavy Duty Box Way Construction
Two Gear Range Headstock
