Rigid Tapping, 20 Position Side Mount Tool Changer, Yellow Operation End Light, Approx. (100) BT-35 Tool Holders, Full Enclosure
Specifications:
Travel: X-Axis 20"
Y-Axis 14"
Z-Axis 18.1"
Table Size 29.9" x 14.96"
Spindle Speed 60 - 6000 RPM
Spindle Taper BT35
Spindle Nose to Table Top 5.9" - 24"
Spindle Motor 7.5 / 5 HP AC
Tools 20
Tool Change Time (T - T / C - C) 1.8 / 7.5 Seconds
Table Load Capacity 880 lbs.
Rapid Traverse Rates (X & Y / Z) 944 / 590 IPM
Max Tool Diameter 3.15" / 5.9"
Max Tool Length 11.8"
Max Tool Weight 13.2 lbs.
Machine Dimensions (L x W x H) 110.2" x 95.7" x 103.1"
Machine Weight 8360 lbs.
FEATURES:
YASNAC MX-3 CNC CONTROL
9" Monochrome CRT
Rigid Tapping
20 Position Side Mount Tool Changer
Yellow Operation End Light
Approx. (100) BT-35 Tool Holders
Full Enclosure
