Rigid Tapping, 15000 RPM Spindle Speed, Fourth Axis Interface, 20 Position Side Mount Tool Changer, Spindle Chiller Unit, Yellow Operation End Light, Full Enclosure
Specifications:
Travel: X-Axis 20.0"
Y-Axis 16.0"
Z-Axis 18.1"
Table Size 29.9" x 14.96"
Spindle Speed 15,000 RPM
Spindle Taper BT 40
Spindle Nose to Table Top 5.9" - 24"
Spindle Motor 15 HP
Tools 20
Tool Change Time (T - T / C - C) 1.8 / 7.5 Seconds
Table Load Capacity 660 lbs.
Rapid Traverse Rates (X & Y / Z) 944 / 708 IPM
Max Tool Diameter 3.15" / 5.9"
Max Tool Length 11.8"
Max Tool Weight 13.2 lbs.
Machine Dimensions (L x W x H) 105" x 100" x 109"
Machine Weight 10,150 lbs.
FEATURES:
YASNAC J300 CNC CONTROL
9" Monochrome CRT
Rigid Tapping
15,000 RPM Spindle Speed
Fourth Axis Interface
20 Position Side Mount Tool Changer
Spindle Chiller Unit
Yellow Operation End Light
Full Enclosure
