Auto Tool Length Measurement, Rigid Tapping, Helical Interpolation

Travel: X-Axis 39.37"
Y-Axis 20"
Z-Axis 18.11"
Table Size 48.81" x 21.65"
Spindle Speed 20 - 3150 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 7.87" - 25.98"
Spindle Motor 20 / 15 HP AC
Spindle Torque 160 ft. lbs.
Tools 30
Tool Change Time (C - C) 8.5 Seconds
Table Load Capacity 1760 lbs.
Rapid Traverse Rates (X / Z) 945 / 708 IPM
Max Tool Diameter 4.92" / 5.9"
Max Tool Length 11.81"
Max Tool Weight 33 lbs.
Machine Dimensions (L x W x H) 101.2" x 148.8" x 119.1"
Machine Weight 17,600 lbs.

FEATURES:
MAZATROL M-32A CNC CONTROL
14" Color CRT
Conversational Programming
EIA/ISO Input Function
Graphic Display
Auto Tool Length Measurement
Rigid Tapping
Helical Interpolation

101 x 149 x 119

17600
