Auto Two Pallet Changer, Auto Tool Length Measurement, Tool Life Monitoring, Tool Breakage Detection, Spindle Chiller Unit
Specifications:
Travel: X-Axis 59"
Y-Axis 32"
Z-Axis 20"
Table Size 68.5" x 29.5" (2)
Spindle Speed 20 - 3150 RPM
Spindle Taper Cat 50
Spindle Nose to Table Top 7.87" - 27.87"
Spindle Motor 12 / 7.5 HP AC
Spindle Torque 318 ft. lbs.
Tools 24
Table Load Capacity 4400 lbs.
Rapid Traverse Rates (X & Y / Z) 551 / 472 IPM
Max Tool Diameter 5.11" / 7.48"
Max Tool Length 11.8"
Max Tool Weight 33 lbs.
Machine Weight 18,700 lbs.
FEATURES:
MAZATROL M-2 CNC CONTROL
14" Color CRT
Graphic Display
Auto Two Pallet Changer
Auto Tool Length Measurement
Tool Life Monitoring
Tool Breakage Detection
Spindle Chiller Unit
