Graphic Display, Rigid Tapping, Helical Interpolation, Auto Tool Length Measurement

Travel: X-Axis 44.09"
Y-Axis 16.14"
Z-Axis 20.08"
Table Size 57.48" x 16.1"
Spindle Speed 40 - 8000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 4.3" - 24.4"
Spindle Motor 15 / 10 / 7.5 HP AC
Tools 24
Table Load Capacity 1120 lbs.
Rapid Traverse Rates (X & Y / Z) 787 / 590 IPM
Tool Change Time (C - C) 9 Seconds
Max Tool Diameter 3.14" / 4.33"
Max Tool Length 13.8"
Max Tool Weight 13.78 lbs.
Machine Dimensions (L x W x H) 118.11" x 116" x 106"
Machine Weight 11,700 lbs.

FEATURES:
MAZATROL M32B CNC CONTROL
12" Monochrome CRT
Conversational Programming
EIA/ISO Input Function
Graphic Display
Rigid Tapping
Helical Interpolation
Auto Tool Length Measurement

118 x 116 x 106

11700
