Graphic Display, Rigid Tapping, Helical Interpolation, Auto Tool Length Measurement, Multi-Tap Transformer, Chip Conveyor (Left Side Exit)

Travel: X-Axis 44.09"
Y-Axis 20.08"
Z-Axis 20.08"
Table Size 57.48" x 20.08"
Spindle Speed 60 - 7000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 4.3" - 24.4"
Spindle Motor 15 / 10 / 7.5 HP AC
Tools 24
Table Load Capacity 1210 lbs.
Rapid Traverse Rates (X & Y / Z) 787 / 590 IPM
Max Tool Diameter 3.14" / 4.33"
Max Tool Length 13.7"
Max Tool Weight 13.78 lbs.
Machine Dimensions (L x W x H) 118" x 116" x 106"
Machine Weight 12,128 lbs.

FEATURES:
MAZATROL M-32B CNC CONTROL
12" Monochrome CRT
Conversational Programming
EIA/ISO Input Function
Graphic Display
Rigid Tapping
Helical Interpolation
Auto Tool Length Measurement
Multi-Tap Transformer
Chip Conveyor (Left Side Exit)

118 x 116 x 106

12128
