Travel: X-Axis 60"
Y-Axis 25"
Z-Axis 25.9"
Table Size 73" x 25"
Spindle Speed 26 - 6000 RPM
Spindle Taper Cat 50
Spindle Nose to Table Top 7.09" - 33.07"
Spindle Torque 280 ft. lbs.
Spindle Motor 20 / 15 HP AC
Tools 24
Table Load Capacity 2600 lbs.
Rapid Traverse Rates 1181 IPM
Tool Change Time (T - T / C - C) 2.0 / 4.7 Seconds
Max Tool Diameter 4.13" / 8.27"
Max Tool Length 13.78"
Max Tool Weight 33 lbs.
Machine Dimensions (L x W x H) 228" x 134" x 133.5"
Machine Weight 26,000 lbs.
FEATURES:
MAZATROL FUSION 640M CNC CONTROL
10.4" Color LCD
Conversational Programming
EIA/ISO Input Function
1.5 MB Memory
3.5" Floppy Disc Drive
Auto Tool Length Measurement
Rigid Tapping
