Rigid Tapping, Helical Interpolation, Heavy Duty Box Way Construction
Specifications:
Travel: X-Axis 42"
Y-Axis 22"
Z-Axis 25"
Table Size 50" x 25"
Spindle Speed 60 - 6000 RPM
Spindle Taper #40
Spindle Nose to Table Top 3.5" - 28.5"
Spindle Motor 22.5 / 15 HP AC
Tools 20
Table Load Capacity 2200 lbs.
Rapid Traverse Rates (X & Y / Z) 708 / 630 IPM
Tool Change Time (T - T / C - C) 3 / 6 Seconds
Max Tool Diameter 6"
Max Tool Length 15"
Max Tool Weight 16 lbs.
Machine Dimensions (L x W x H) 127" x 110" x 107"
Machine Weight 15,000 lbs.
FEATURES:
MITSUBISHI MELDAS 320M-V CNC CONTROL
9" Monochrome CRT
Rigid Tapping
Helical Interpolation
Heavy Duty Box Way Construction
Mfg Date January 1995
