Custom Macros, Stored Pitch Error Compensation, Auto Power off, Rigid Tapping, Helical Interpolation, RS-232 Interface, Yellow Operating Condition Light, Table Chip Guards, Two Gear Range Headstock, Heavy Duty Box Way Construction
Specifications:
Travel: X-Axis 58.5"
Y-Axis 28.5"
Z-Axis 24.5"
Table Size 63" x 30"
Spindle Speed 50 - 4250 RPM
Spindle Taper BT50
Spindle Nose to Table Top 7.4" - 31.9"
Spindle Motor 20 HP AC
Tools 20
Table Load Capacity 3000 lbs.
Rapid Traverse Rates 590 IPM
Max Tool Diameter 6"
Max Tool Length 15"
Max Tool Weight 33 lbs.
Machine Dimensions (L x W x H) 149" x 110" x 110"
Machine Weight 25,000 lbs.
FEATURES:
MITSUBISHI M520A CNC CONTROL
9" Monochrome CRT
Graphic Display
Custom Macros
Stored Pitch Error Compensation
Auto Power Off
Rigid Tapping
Helical Interpolation
RS-232 Interface
Yellow Operating Condition Light
Table Chip Guards
Two Gear Range Headstock
Heavy Duty Box Way Construction
