MANUFACTURED NEW 2004
TABLE SIZE 45" x 24"
MAXIMUM TABLE LOAD 3,000 LBS
SPINDLE NOSE TO TABLE TOP 4.25" - 28.25"
X AXIS TRAVEL 40"
Y AXIS TRAVEL 24"
Z AXIS TRAVEL 24"
RAPID TRAVERSE RATE X, Y & Z AXES 1000 IPM
CUTTING FEED RATE 0.1 - 400 IPM
SPINDLE TAPER CAT 40
SPINDLE SPEEDS 0 - 10,000 RPM
SPINDLE MOTOR 30 HP
TOOL CHANGER CAPACITY 24 STATION ATC
MAXIMUM TOOL WEIGHT 12 LBS
MACHINE WEIGHT 13,500 LBS
APPROXIMATE DIMENSIONS 109" x 77" x 98" w/chip auger
Equipped with:
Centurion 6 Control
RS-2323 Port
Sidemount ATC
Chip auger
