24 Position Side Mount Tool Changer, 8" Yuasa CNC Rotary Indexer, Portable Pendant Control, Spindle Chiller Unit, Remote Manual Pulse Generator, Chip Auger, Heavy Duty Box Way Construction
Specifications:
Travel: X-Axis 39.4"
Y-Axis 23.6"
Z-Axis 21.7"
Table Size 55.1" x 23.6"
Spindle Speed 40 - 6000 RPM
Spindle Taper Cat 50
Spindle Nose to Table Top 7.9" - 29.6"
Spindle Motor 20 HP
Spindle Torque 221 ft. lbs.
Tools 24
Table Load Capacity 2600 lbs.
Tool Change Time (T - T) 2 Seconds
Rapid Traverse Rates (X & Y / Z) 590 / 472 IPM
Max Tool Diameter 4.7" / 9.4"
Max Tool Length 15.7"
Max Tool Weight 33 lbs.
Machine Dimensions (L x W x H) 102" x 100" x 108"
Machine Weight 22,000 lbs.
FEATURES:
MITSUBISHI MELDAS CNC CONTROL
14" Color CRT
24 Position Side Mount Tool Changer
8" Yuasa CNC Rotary Indexer
Portable Pendant Control
Spindle Chiller Unit
Remote Manual Pulse Generator
Chip Auger
Heavy Duty Box Way Construction
