USED MITEK MODEL MK-45 PLUNGE TYPE EDM
MACHINE, 30 AMP

DK-12495 S/N 0228880 NEW 1991 (APPROX.)

SPECIFICATIONS:

SIZE OF WORKING TABLE:24" X 12"
SIZE OF WORKING TANK:35" X 21" X 13"
X-AXIS TRAVEL:12"
Y-AXIS TRAVEL:10"
RAM TRAVEL:6"
WORKHEAD TRAVEL:8"
DISTANCE FROM ELECTRODE TO WORKING TABLE:18"
HAND FEED (X, Y AXIS)
PER GRADUATION:0.001"
PER REVOLUTION:0.2"
MAXIMUM WORKPIECE WEIGHT:660 LBS
MAXIMUM ELECTRODE WEIGHT:155 LBS
RESERVOIR CAPACITY:80 GALLONS
MACHINE WEIGHT:2,000 LBS

ELECTRICS:220 VOLTS, 3 PH, 60 CYC

EQUIPPED WITH:

MODEL 30 POWER SUPPLY, S/N 8008008
BALL SCREWS ON X, Y AXIS
FLUSHING NOZZLE
