Auto Two Pallet Changer, 30 Position Side Mount Tool Changer, Coolant Thru Spindle, Rigid Tapping, Helical Interpolation, Chip Conveyor (Rear Exit), Full Enclosure, Heavy Duty Box Way Construction
Specifications:
Travel: X-Axis 31.5"
Y-Axis 16.4"
Z-Axis 20.1"
Table Size 36" x 15.2" (2)
Spindle Speed 8000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 5.9" - 24"
Spindle Motor 10 / 7.5 HP
Tools 30
Table Load Capacity 1540 lbs.
Rapid Traverse Rates (X & Y / Z) 787 / 590 IPM
Tool Change Time (T - T / C - C) 1.5 / 5.2 Seconds
Max Tool Diameter 3.1" / 4.5"
Max Tool Length 11.8"
Max Tool Weight 17.6 lbs.
Machine Dimensions (L x W x H) 97.6" x 88.6" x 100.4"
Machine Weight 13,310 lbs.
FEATURES:
MORIC MSC-516 (FANUC 16M) CNC CONTROL
9" Monochrome CRT
Auto Two Pallet Changer
30 Position Side Mount Tool Changer
Coolant Thru Spindle
Rigid Tapping
Helical Interpolation
Chip Conveyor (Rear Exit)
Full Enclosure
Heavy Duty Box Way Construction
