Rigid Tapping, Helical Interpolation, Chip Shute, Full Enclosure, Two Gear Range Headstock, Heavy Duty Box Way Construction
Specifications:
Travel: X-Axis 31.5"
Y-Axis 16.1"
Z-Axis 20.1"
Table Size 43.3" x 17.7"
Spindle Speed 30 - 8000 RPM
Spindle Taper Cat 40
Spindle Nose to Table Top 5.9" - 26"
Spindle Motor 10 / 7.5 HP AC
Tools 20
Table Load Capacity 1540 lbs.
Rapid Traverse Rates (X & Y / Z) 787 / 590 IPM
Tool Change Time (T - T / C - C) 1.5 / 5.2 Seconds
Max Tool Diameter 3.1" / 4.9"
Max Tool Length 9.8"
Max Tool Weight 17.6 lbs.
Machine Dimensions (L x W x H) 97.6" x 88.6" x 109.1"
Machine Weight 13,310 lbs.
FEATURES:
YASNAC i-80 CNC CONTROL
9" Monochrome CRT
Rigid Tapping
Helical Interpolation
Chip Shute
Full Enclosure
Two Gear Range Headstock
Heavy Duty Box Way Construction
