Coolant Thru Spindle Interface, 30 Position Side Mount Tool Changer, Spindle Chiller Unit, Rigid Tapping, Full Enclosure
Specifications:
Travel: X-Axis 23.6"
Y-Axis 16.9"
Z-Axis 18.1"
Table Size 34.4" x 19.7"
Spindle Speed 12,000 RPM
Spindle Taper Cat 40
Spindle Torque 122.9 ft. lbs.
Spindle Nose to Table Top 5.9" - 24"
Spindle Motor 30 / 24.8 HP
Tools 30
Table Load Capacity 1100 lbs.
Rapid Traverse Rates 1260 IPM
Tool Change Time (T - T / C - C) 2.8 / 3.3 Seconds
Max Tool Diameter 3.1" / 4.9"
Max Tool Length 11.8"
Max Tool Weight 26.4 lbs.
Machine Dimensions (L x W x H) 160.4" x 95.5" x 106"
Machine Weight 11,420 lbs.
FEATURES:
MORIC MSC-518 (FANUC 18iMA) CNC CONTROL
10.4" Monochrome LCD
Coolant Thru Spindle Interface
30 Position Side Mount Tool Changer
Spindle Chiller Unit
Rigid Tapping
Full Enclosure
