x-travel 2000 mm
y-travel 400 mm
z-travel 400 mm
dist. up to lower edge of vertical spindle 200/600 mm
table surface area 2120 x 450 mm
table load 2 t
feeds longditudinal/cross/vertical 1 - 8000 mm/min
rapid motion -longitudinal/cross/vertical 25 m/min
power feed longitudinal 8400 N
spindle motor 18,5 kW
max. torque on the spindle 120 Nm
spindle turning speed range 20 - 6300 U/min
spindle taper ISO 40
no. of workpieces in the magazine 40 Stück
max. tool-dia with free toolbox 105 mm
max. tool weight 4/8 kg
total power requirement 45 kW
weight of the machine ca. 10 t
dimensions of the machine ca. m
