X-axis 500mm
Y-axis 400mm
Z-axis 400mm
Length standard Reflective linear encoder
Resolution 0.0005mm (.00002")
Accuracy (20.C)* E=(4.0+5L1000)m
Guide method Air bearing for each axis
Maximum workpiece height*** 482mm
Maximum workpiece weight 160kg
Air pressure 0.4MPa (4kgf/cm2) or 58 PSI
Air consumption 40 liters per minute (in normal state) or 1.44 CFM
Dimensions Width 1074mm
Dimensions Depet 938mm
Dimensions Height 437kg
Mass (including the mass of the machine stand) 2238mm
