YOM: 1998
Year of inspection: 2016
CNC HEIDENHAIN TNC 426PB

Table dimensions: 4000 x 1250 mm
Number of T slots: 8
T slots dimensions: 22 mm

X axis traverse (mm): 3500
Y axis traverse (mm): 2000
Distance between columns: 1740 mm
Z axis traverse (mm): 800

Head type:CHM Manual angled head
Tool clamping system: Hydraulic
Taper nose: ISO 50
Speed range: 2 – 5000 rpm
Spindle power: 30 kW
Max torque: 725 Nm

Feedrate: 7.000 mm/min
Rapid feedrate (X / Y , Z): 15000 / 12000 mm/min

Max weight on table: 10000 kg
Machine weight: 30500 kg
Machine dimensions: 10748 x 4762 x 4400 mm

Guarding
Automatic tool changer (ATC-60)
Coolant through spindle: high pressure
Head support in column
Transversal chip conveyor
Electronic handwheel: HR-410
Work probing: Reninshaw MP14 & TS27R
Guarateed
