Diameter of spindle: 4”
#50 Taper in spindle
Vertical spindle travel: 60”
Horizontal spindle travel: 20”
Spindle speeds from 27 to 2500 RPM
Table size: 35” X 72”
Table travels:
Longitudinal – 72”
Retraction – 16”
Table load capacity: 11,000#
Rapid traverse in all directions up to 400 IPM in X and Y
Equipped with:
Dynapath Delta 20 4 Axis controls with CRT
Variable speed spindle drive and 20 HP motor
Heidenhain scales
Spray mist coolant
Electrical motors and controls
Dimensions: FB X RL – 177” X 204”
Height: 154”
Est. weight: 44,000#
