SELCA 3045 WITH ELECTRONIC CONTROL KNOBS
HANDLING SINGLE AXIS
IN CONTROL PULPIT.
TOOL MAGAZINE TDC 22 DOUBLE TRAP AND 22 STATIONS.
RPM RPM SPINDLE 5500
AXIS CROSS SLIDE WITH BUILT
CHUCK THE HORIZONTAL.
CONE SPINDLE ISO 40.
VERTICAL HEAD WITH BOAT SLIDE
(90 mm TRAVEL) CHUCK AND WORKING
WITH ISO 40 / DIN 69871.
TABLE SCQUADRA 600 X 1200.
HYDRAULIC SYSTEM OF RAPID RELEASE OF TOOL.
STROKE AXIS X 900 mm
RUNNING Y AXIS 630 mm
STROKE AXIS Z 500 mm
ADJUSTABLE FOR REMOVAL AND
MOVING HEAD VERTICAL.
HYDRAULIC FOR AUTOMATIC LUBRICATION OF ACES
GROUP COOLANT PUMP WITH CAPACITY OF 20 LITRES.
TANK REFRIGERANT
CABIN PARATRUCCIOLI AND SPRAY PARA SAFETY

-
