STROKE AXIS X: 700 mm
Y-AXIS STROKE: 480 mm
STROKE AXIS Z: 510 mm
DISTANCE SPINDLE NOSE
UP TABLE: 150-660 mm
DISTANCE COLUMN AXLE
CHUCK: 544.5 mm
RAPID FEEDS
XYZ: 36-36-24 m / min
CHUCK: 8000 rpm;
5.5-7.5 Kw;
BT 40
DIMENSION
TABLE: 800x460 / mm
WAREHOUSE
TOOLS: 24 POS
MAX LOAD
ADMITTED: 500 Kg
LENGTH MAX
TOOL: 250 mm
DIAMETER MAX
TOOL: 80 mm
WEIGHT MAX TOOL: 8 kg
POWER REQUIRED: 23 kVA
CONTROL: FANUC 0i-MF
INGOMBRO_L: 2123 mm
INGOMBRO_P: 2350 mm
INGOMBRO_H: 2550 mm
