Planer type miller DROOP & REIN
Type: FP 140/3
Serial number: 2436
Max. weight of workpiece: 30000 kg
Vertical spindle: 24-1200 r/min
Spindle right and left: 24-1200 r/min
Distance passable between columns: 2800mm
Travel of X: 4500mm
Travel of Y: 2780mm
Travel of Z: 1300mm
Quill of the vertical head: 400mm
Motor power of three heads: 20kw
Vertical Travel of horizontal heads: 1300mm
Quill of the two horizontal heads: 300mm
Table: 2000x4000mm
Spindle cone: ISO 50
9 magnetic tables
Production year: 1969
Dimension of machine: 7300x10400mm
Weight of machine: 91000 kg

-
