working surface 3000 x 6000 mm
Condition: very good, complete set.
Specifications:
9-axis CNC: General Electric Century 550MBD.
Distance between columns (machinable width) 3600mm
Table dimensions: 3000x6000mm
Max. height of work piece: 2600mm
Height under spindle: 3000mm
Stroke of table: 6000mm
Range of working movement of the table: 0...3000mm/min
Rapid movement of the table: 8000mm/min
Carrying capacity of table: 10ton/metre
Stroke of walking cross rail: 2500mm
Working movement of the walking cross rail: 1200mm/min
Stroke of slide: 3800mm
Range of working movement of the slide: 0...3000mm/min
Working movement of the of slide: 3000mm/min
Slow working movement of the of slide: 3mm/min
Automatic tool changer:
Number of cutting tools: 20
Max. weight of cutting tools: 25 kg
Max. diameter of two successive cutting tools: 150mm
Max. length: 300mm
Max. diameter of milling cutter: 250mm
Weight:150t
