- 1194mm x 422mm table size
- 965mm x 380mm working surface
- x axis 760mm
- y axis 380mm
- z axis 125mm-Spindle
- knee travel 335mm
- throat dist. 395mm
- table to spindle 478mm
- max component weight 450kgs
- 1.5kW spindle motor
- 50-3750 rpm spindle speeds # 30 taper
- 10-750mm/min manual feedrate
- 5000mm/min rapid feedrate
- 1-5000mm/min programmable feedrate
- 1mm/min feedrate increments
- 20mm dia. drilling capacity
- 100mm dia max boring
- Heidenhain TNC 150 CNC conrol
- Weight 1200 kg
- Dimensions 1,6x1,6x2,25 m
Operators Manual
Electrical Diagrams

-
