MAJOR SPECIFICATION
SpecificationUnitTF-4SSTF-4HSTF-4VS
Spindle Taper R8/NT30 (∮86mm)NT40 (∮105mm)R8/NT30(∮86mm)
Number of Spindle Speeds 1616Variable
Range of Spindle Speeds RPM80-453060-477050-3500
Downfeeds of Spindlerev/mm0.04-0.08-0.160.04-0.08-0.160.04-0.08-0.16
Number of Downfeed 333
Spindle Travel 127127127
Head Movement
(Right and left)angle90°90°90°
Head Movement
(Front and behind)angle 45°45°45°
Distance Spindle to Tablemm485485485
Distance Spindle to Column(Max)mm670670670
Distance Spindle to Column(Min)mm150150150
Collet Capacitymm3-223-223-22
Size of Tablemm250×1270250×1270250×1270
Longitudinal Travel of tablelmm760760760
Cross Travelmm380380380
T-Slot Number &Sizemm3(16)3(16)3(16)
T-Solt Centersmm646464
Max Weight of Workpiecekg320320320
Travel of Kneemm420420420
Overarm Travelmm320320320
Slide of Knee SquareSquareSquare
Slide of Column Dovetail SlotDovetail SlotDovetail Slot
Overall Dinensionmm2430/1740/21002430/1740/21002430/1740/2100
Motor 2.2KW,3PH,50HZ3.75KW, 3PH,50HZ2.2KW,,3PH,50HZ
