movements: - Longitudinal movement of table (x) 1120 mm - cross slide transversely-(y) 345 mm - console vertical motion (z) 400 mm table size: 400 x 1600 mm table load: 1500 kg tool Recording: SK 50 diameter front bearing : 100 mm quill: 90 mm Spindle head swivel range: 45 degrees on both sides drive spindle power: 11 kW Speed range: 28 1400 U / min Max torque: 1850 Nm feed rates [...Technical data truncated]
