Specifications: Control: conventional clamping table for details: Path of mechanical movement of the worktable: 315mm width x length x 1250mm Number Aufspannuten: 4 motion X-axis (longitudinal): 850mm Y-axis movement (traveled all): 270mm Z-axis movement ( vertical): 355mm way of manual movement of the worktable: X-axis: 880mm Y-axis: 1030mm Z-axis: 385mm Maximum mass of workpiece: 1000kg swiveling range of the worktable to each side: 45 degrees console cut: 0.7 mm data to the work area: Information to the milling spindle: Wergzeugaufnahme: spindle head 50 TGL 7836 (ISO 50 taper) diameter bearing on the Middle: 110mm largest diameter head diameter: 250mm max. Allowable Torque on the spindle: 1850Nm axial adjustment of the spindle by spindle: 90mm swivel range of the spindle on each side: 45 degrees of spindle speeds: Number of stages: 18 increment: 1.25 range rpm / 28 .. 1400 Feeds: Number of levels: 18 increment: 1.25 range X, Y mm / min: 16 .. 800 range Z mm / min: 5 .. 250 Rapid traverse: X, Y mm / min: 3150 rpm Rapid traverse Z mm / 1000 data to electrical equipment: Power: Spindle: 5.5kW feed 1.5 kW Description: The machine is suitable for use in the series and also in the individual production. It can be machined in the mating and in unison. A hydraulic lowering device allows the AUTOMATIC
