Working Range
Milling length: 2000 mm
Centre height above bed slideway: 260 mm
Max workpiece diameter above bed slideway: 500 mm
Max workpiece diameter above milling saddle: 250 mm
Bore of work spindle: 102 mm
Max bore of collet chuck: 100 mm
Traverse length of tailstock quill: 100 mm
Pitch of leadscrew: 1/2 LH inch
Rotation speed of workpiece (Thread Milling)
Range, infinitely variable: 0,0032/2.6 rpm
Feedrates
Hobbing, infinitely variable range: 0,027/5.66 mm/work.rev
Straight milling, infinitely variable range: 0,3/198 mm/min
Rapid traverse
Thread milling with lead (1-1000mm) : 10,9/1090 mm/min
Thread milling with lead (100-800mm) : 816 mm/min
Hobbing: 816 mm/min
Straight milling: 816 mm/min
POWER
Mainmotor: 4 kW
Rated torque / feed motor : 25 Nm
Coolant pump: 0,09 kW
Lube-oil pump: 0,37 kW
Electric Equipment
Operating voltage: 380 volt
Control voltage: 24 volt
Frequency: 50 Hz
Connected load total: 9.5 kW
Space required for
Milling length: 2000
Length: 4000 mm
Width: 2500 mm
Height: 1600 mm
Net weight: 4300 kg
Capacity of coolant: 40 ltr

-
