Specifications: Spindle Horiz. and vert. SK 40 turning of the cutter head 360 to re scale / li 50 12 spindle speeds Vertical 31.5 - 1400 rpm /. Horizontal 22.4 to 1000 U / min. Adjustment of the vertical spindle travel 100 mm 360 mm 1000 mm cross Länges vertical movability of the quill 450 mm 100 mm 18 longitudinal and cross feeds from 12.5 to 630 mm / in. Vertical 6.3 - 315 mm min /. Rapid longitudinal and transverse min 1250 and 2500 mm / min. Vertical 630 and 125 mm / min. Total power 7,1 KW Anrtiebsleistung 5.5 KW Dimensions LxWxH (space) 2280 x 3050 x 2070 mm, weight 2900 kg
