Table size : 355 x 786 mm
T - slot ( Wide x Number) : 14 x 3
Max. loading weight : 240 kg
Travel lengthways ( x - axis) 510 mm
Travel across ( y - axis) 355 mm
Travel vertical (z - axis) 405 mm
Distance - table top - spindlehead : 127 - 532 mm
Distance - Stand - Table center line : 202,5 - 557,5 mm
Spindle cone : NST Nr. 35
Speed : 150 - 10000 U / min
adjustable speed : Continuous belt drive
Feed rapid traverse ( x, y axis): 24 m / min
Feed rapid traverse ( z - axis): 20 m / min
Cutting feed : 0 - 10000 mm / min
Tool memory : 20
Tool selection : Directly control
Tool holder : MAS BT 35
Max. Tool size : 70 x 250 mm
Adjacent tool station ( empty) 100 x 250 mm
max. Tool weight : 4 kg
Tool change time : 1,5 sec
Tool change time chip to chip: 5,5 sec.
Spindle motor: AC 5,5 / 3,7 KW
Machine height : 2.768 mm
Footprint : 2.020 x 1.980 mm
Machine weight: 2.800 kg

-
