"ERCOLINA GIGA BENDER Semi-automatic 5-axis NC mandrel bending machine up to 88.9 mm (see Performance table) properties: bending radius: R40 to R300 (min R = 1,5 xD) depending on the thickness, the material and the pipe diameter to use: 7.5 Touch-screen control panel and joystick Number of Programs: 2000 via a USB memory stick bending Rich Ting: left Effective Length: 4000 mm Dimensions (W x H x D): 1570 x 1498 x 5500 mm Weight: 2340 kg Automatic mandrel lubrication Premature Dorn withdrawal Power: Hard copper and aluminum: 88.9 x 6 mm steel tube: 88.9 x 3 mm stainless steel: 88.9 x 1.5 mm Package: GB90 NC5 S (4000) standard accessories (including control panel, bending fat, 25 mm mandrel) delivered without hydraulic oil (100 liters required) [...Technical data truncated]
