Machine dimension : 1235x600x1975 mm
Weight : 1250 Kg
Technical characteristics
Power : 60 Tonnes
Maxi hit rate : 13 cps/min (stroke/min)
Motor power : 5.5 CV
Electrical supply : 380 V,50Hz
Capacity
Punching : Dia 28 x 16 mm
Shearing : 350 x 16 mm
Angle at 90° : 100 x 100 x 10 mm
Tube : 45 mm
Square : 42 mm
Notching : OUI
Thickness : 13 mm
Width : 42x76 mm
Specifications:
Power : 60 Tonnes
Maxi hit rate : 13 cps/min (stroke/min)
Motor power : 5.5 CV
Electrical supply : 380 V,50Hz
Punching : Dia 28 x 16 mm
Shearing : 350 x 16 mm
Angle at 90° : 100 x 100 x 10 mm
Tube : 45 mm
Square : 42 mm
Notching : OUI
Thickness : 13 mm
Width : 42x76 mm
