Controls: conventional

PRESS DESIGN
frame design C-frame, single si
number of slide actions 1
number of cushions 1

PRESS FORCES
total force (nominal) ( 2500 kN) 250 to

PRESS TABLE
table surface (left-right) ( 70.92 " ) 1800 mm
table surface (front-back) ( 35.46 " ) 900 mm
distance between ejector holes ( 5.91 " ) 150 mm

RAM
ram force ( 2500 kN) 250 to
table surface (left-right) ( 39.4 " ) 1000 mm
table surface (front-back) ( 29.55 " ) 750 mm
stroke ( 6.304 " ) 160 mm
stroke rate (max.) 35 /min

RAM (MECHAN. PRESS)
ram adjustment ( 5.122 " ) 130 mm
autom. ram adjustment yes
stroke adjustment yes
stroke min. ( 0.788 " ) 20 mm
stroke max. ( 6.304 " ) 160 mm

DIE CUSHION (TABLE CUSHION)
number of cushions 1
cushion force ( 250 kN) 25 to
working principle pneumatical

TOOL ASSEMBLY DIMENSIONS
shut height (stroke down, adjustment up) (15.957 " ) 405 mm

ELECTRICAL SPECIFICATIONS
total power consumption (30.172 hp) 22.5 kW
mains voltage 380 V
mains frequency 50 Hz

DIMENSIONS / WEIGHTS
space requirements length ( 70.92 " ) 1800 mm
space requirements width (100.08 " ) 2540 mm
total height (136.72 " ) 3470 mm

ATTACHMENTS (PRESSES)
2-hand engagement

-
