--- We can give nothing but cheap to sell, we do! Please convince yourself that this price is cheap! Make: TOS Type: 2 UD / 750 machine no. 27 678 Year: 1985 * / 2012 TÃP. Comm Number 3991260/009 Specifications: Height: 145 mm Voice - 290 mm turning length: 750 mm Wheel Diameter: 350 mm Bore - 127 mm Maximum width of a full wheel in plunge: 50 mm Maximum overall width of a wheel set: 100 mm largest sum of the widths: 50 mm grinding wheel rotation: 1.640 / 1.950 U / min. Grinding head rotation of the grinding head left - right: each 90 Biggest Schleifkopfhub: 220 mm Maximum lift above wheel: 180mm Additional Stroke: 95 mm Auto feed interval: 0.005 - 0.05 mm at a feed handwheel: 2.0 mm feed on hand wheel -graduation: 0.005mm Eilweg of grinding head: 35 mm Maximum delivery based on the diameter: 0.05 - based 3.0 mm infeed with touch control on the diameter obtained 0,005 mm infeed with micro attack on the diameter: 0,001 mm workpiece spindle head: 6 workpiece speeds Adjustable: 38 - 380 U min /. Rotation of the workpiece spindle head against the grinding wheel 90 spindle cone, or inside the workpiece spindle taper: MT3 tailstock internal taper of quill: MT3 Spindle stroke: 40 mm Table: Largest table tilt: each 7 Gröss [...Technical data truncated]
