Number of the centers of pressure of the slide block of the stretch former 4

The maximum force of the slide block of the stretch former to distance of 25 mm before the bottom top dead centre 10000 kN

The maximum force of the slide block of the stretch former to distance of 350 mm before the bottom top dead centre 5000 kN
The maximum force of the tightening slide block to distance of 10 mm before the bottom top dead centre
6300kN
STEPLESS VARIATION
Number of duty idle courses, 8....16 min
Power of the principal electric motor (at the maximal number of duty idle courses
nH=16 ) 197 kw
The maximum speed of the exhaust slide block press in a limit of a downyard (at a maximum number of idle running nH=16) 400 mm/sec
Kinetic energy of moving details on all numbers of a course in control ranges 315 кДж

The basic overal dimensions

Width between racks of 4600 mm
Course of the exhaust slide block press of 900 mm
Course of the tightening slide block 700 mm
The maximum depth of a downyard 350 mm
Adjustability of both slide blocks on 350 mm

-
