Maximum pressure: 40 Tn
Strokes for minute: 130
Variable strokes for minute: 70-200
Motor power: 4 kW
Adjustable stroke: 5-75 mm
Ram adjustment: 50 mm
Distance table-ram: 330 mm
C-Frame depth: 205 mm
Distance between shoulders: 245 mm
Table dimensions: 405 x 670 mm (LxM)
Bolster plate thickness: 60 mm
Table hole diameter: Ø120 mm
Ram surface: 155x315 mm
Ram hole diameter: Ø 38 mm
Inclination angle: 18º

-
