Friction clutch, flywheel drive, fixed table, front end support, rupture protection, hand lubrication, x with motor 3 kW, 710 min-1, 380 volts, Weight 3050 kg pressure for about 40 t throat 240 mm, ram adjustment 63 mm ram area approximately 250 200 mm Hubverstellbarkeit of about 8 - 88 mm stroke rate 130 min-1 table size 560 x 450 mm in Durchfalloch table around. 200 mm Distance between table and ram stroke gr at about 280 mm below 380 volt electrical connection
