Condition: good, full complete
Technical specification:
Capacity: 2500 ton
Slider stroke length, mm: 320
Slider adjustment, mm: 10
Number of courses of a slider per minute: 65
Shut height, mm: 900
Working surface of slide, mm 1320x1100
Working surface of table, mm 1340x1400
Dimensions of the machine:
- length – left to right, mm: 4 025
- width – front to back, mm: 3 290
- height above floor, mm: 6 620
- total height, mm: 7 300
Output of main motor, kW: 130
Consumption of pressured air, dm3/stroke: 160
Weight of the machine, kg: 125 000
