Condition: good, full complete
Technical specification:
Force: 3150 ton
Ram stroke: 360 mm
Number of ram strokes per min: 65
Shut height: 1000 mm
Ram adjustment: 20 mm
Width between uprights: 1580 mm
Stroke of upper ejector: 50 mm
Ejecting force of upper ejector: 105 kN
Stroke of lower ejector: 50 mm
Ejecting force of lower ejector: 410 kN
Press height above floor: 6535 mm
Press height: 7335 mm
Press width: 4615 mm
Press depth: 4266 mm
Main drive motor output: 160 kW
Air consumption (cdm per stroke): 640 dm3
Water consumption: 12 dm3/min-1
Press weight: 200 000 kg

-
