LOWER ACTION - RAM
Closing capacity , adjustable kN 10.000
Max daylight between plates: mm 400
Min daylight between plates: mm 200
Slide stroke: mm 200
Bolster/Slide useful dimensions: mm 600 x 600
MAIN MOTOR: kW 37
SPEED
Quick closing: mm/sec 100
Pressing: mm/sec 3
Fast return: mm/sec 100
OVERALL DIMENSIONS Base: mm 2.490 x 990
Max Height over floor level: mm 2.660
Foundation not required Working table over floor level: mm 1.200

-
